No

Description

Qty

USD/SET

Amount

1

Plastic Extrusion Blow Molding (EBM) Machine, Model PGB02LII4,
Screw 50mm, 4 Dieheads, 2 Stations,
For 1 Layer Bottles Production, Maximum Bottle 2L,
Suitable for PE/PP Materials, Output ~1,440pcs/hour Bottles

1 Set

29,926

29,926

5,412

5,412

5,412

5,412

2,875

5,750

Remarks: The prices are calculated on USD100=RMB682 basis, if the exchange rate fluctuates more than 1%, the prices should be adjusted in last payment according to http://www.bank-of-china.com/en/common/service.jsp
Payment: by 40% T/T prepayment plus 60% T/T payment before delivery
Lead Time: 10 days for bottles' drawings confirmation, 45 days for production, plus 10 days for improvements if necessary, not including samples mailing and approval days.
Installation: The manufacturer installs and debugs the whole production line in China till good running, Buyer might come to China for training and quality checking and accepting procedures at Buyer's costs.
Quality Guaranteed Period: One year if Buyer correctly operates equipments and keep necessary maintenances. Of course, those wearing parts are not listed in guaranteed list. The manufacturer offers long term technical supports and spare parts at costs level.
Offer Date on Dec.31st, 2009

Please contact with Mr.HuaLong Lin to know if this offer is still valid.

PGB2LII Series

PGB2LII/1

PGB2LII/2

PGB2LII/3

PGB2LII/4

Basic Datas

Suitable Plastics

PE, PP, PA, PVC

PE, PP, PA

Maximum Bottle

2L

800mL

500mL

350mL

Null Cycle Time

4 Seconds or 900Cycles/Hr

Machine Size

2.8*1.9*2.2m

Machine Weight

4MT

Installed Capacity

36KW

Average Energy Consumption

14.8KW

Plasticizing System

Screw Diameter

Fi 60mm

Screw L/D Ratio

22

Plasticizing Capacity

65Kg

Heating Zones Number

3

Heating Power

11.5KW

Extrusion Motor Power

15KW

Extrusion Diehead

Center Distance of Dieheads

—

130mm

110mm

60mm (80mm)

Heating Zones Number

3

4

4

4

Heating Power

4KW

4.5KW

5KW

5.2KW

Maximum Mouth

Fi 90mm

Fi 60mm

Fi 40mm

Fi 30mm

Mold

Clamping Force

30KN

Distance of Mold Plates

138~368mm

Sizes of Mold Plates (W*H)

300*350mm

Electric Control System

Temperature Control

Data Communication

Process Time

Data Communication

Working Pressures

Proportion/Pressure/Parameters Control

Hydraulic System

Oil Pump's Motor Power

5.5KW

System Pressure

10MPa

Pneumatic System

Air Source Pressure

0.6Mpa

Air Source Discharge Capacity

0.8M3/min

Cooling System

Water Source Pressure

0.2—0.3MPa

Water Source Flow

45L/min
